The US Department of Commerce has signed letters of intent with seven companies for up to $874 million in semiconductor research funding. The department’s National Institute of Standards and Technology published the announcement on July 29, 2026. NIST says the program uses research funding authorized through the CHIPS and Science Act.
What this stage means
A letter of intent is not the same as a final funding agreement. According to NIST, the companies must complete additional due diligence and approval steps. The announced $874 million therefore represents the combined upper limit of possible support for seven companies. The money has not yet been finalized or fully distributed.
That distinction is central to the announcement. The department will continue working with the companies, reviewing the projects and evaluating final terms separately. The use of “up to” also means the final amounts could be lower than the published ceilings. At this stage, the documents show which research areas the federal program is prepared to consider.
The technical scope
NIST says the program covers areas including integrated photonics, new computing architectures, advanced packaging, semiconductor substrates, materials and memory technology. The funding framework is not limited to one chip design or one production line. It brings separate research proposals from different companies into the same federal review process.
The department also connects the research areas to artificial intelligence and next-generation computing. However, the announcement does not guarantee that the projects will achieve their technical goals. Support remains subject to technical and financial review. The accurate focus is therefore the proposed research framework rather than completed investments.
Up to $300 million for GlobalFoundries
GlobalFoundries has the largest published ceiling among the seven companies. It could receive up to $300 million for work involving co-packaged optics. A July 29 statement from GlobalFoundries confirms both the letter of intent with the Department of Commerce and the potential $300 million award.
The company says the research would focus on silicon photonics and advanced packaging. Silicon photonics uses semiconductor-based technology for optical data connections. GlobalFoundries links the planned work to expanding research and manufacturing capabilities in the United States. The company still describes the support as an expected award rather than a completed payment.
Seven separate reviews
NIST does not describe the seven companies as participants in a single joint project. Each company has its own research proposal, technical field and possible funding ceiling. The headline amount combines those seven proposed limits. A final decision involving one project would not automatically settle the status of the other six.
The range of technical fields also shows that semiconductor development extends beyond producing processors. Packaging, photonic connections, memory, materials and substrates represent different parts of the hardware chain. NIST’s announcement places those distinct layers within one research strategy while keeping the individual projects separate.
What happens next
The next phase will involve detailed discussions between the department and the companies, followed by the required reviews. Final awards can be completed only after those steps. The confirmed development at this point is the creation of a proposed funding framework worth up to $874 million across seven companies through signed letters of intent.
The official NIST release establishes the overall program, while the GlobalFoundries statement confirms the company side of the largest proposed package. Read together, the sources show that the announcement is significant but still preliminary. Any future report on completed awards will require a separate final decision from the Department of Commerce.
